Carlson RT4+ Tablet Data Collector

$5,450.00$5,650.00

The Carlson RT4+ is designed for surveying, stakeout, construction layout, and GIS mapping and is bundled with Carlson SurvPC – the Windows-based data collection program. The RT4+ can also be used in the office with any Carlson office software. With Windows 11, 16GB of RAM and 256 GB of storage, you’ll have the power to collect and analyze your data faster and more efficiently than ever before.



See Available Discounts in Cart

Add Additional Software:

Add Accessories:

Quantity:
SKU: N/A Category:

Description

PERFORMANCE

Powerful Intel N200 3.7GHz processor
Now with 16GB RAM & 256GB flash storage
Faster display with Intel’s Gen12 UHD graphics

EXPANDABLE BATTERY

All-day battery runs up to 15 hours for minimal downtime
Operates in extreme temperatures from -4°F to 122°F (-20°C to 50°C)

READY FOR ANYTHING

Windows 11 for office-to-field use
Long-range Smart Ready Bluetooth®, Wi-Fi®, USB connectivity
Improved 13 MP rear (with LED) and 5 MP front cameras
4G LTE ready for RTK Mobile or other carriers
High-performance GNSS receiver

RUGGED

Maximum protection for your data
Dustproof & waterproof (IP68 rating)
Designed to MIL-STD-810G for ultra-ruggedness
2-year warranty

ILLUMIVIEW™ HIGH-VISIBILITY DISPLAY

Large, 7-inch display for easy viewing
IllumiView technology provides extraordinary visibility
Optically-bonded capacitive touch screen for needle-sharp imagery
Chemically-strengthened Dragontrail™ HW glass for excellent impact & scratch resistance

Documentation

Carlson RT4 Tablet Data Collector Brochure

Processing/Power

PROCESSOR

Intel® N200, 3.7 GHz burst

OPERATING SYSTEM

Microsoft® Windows 11
Multiple languages supported (English, French, Spanish, German, Portuguese)

MEMORY AND DATA STORAGE

16 GB RAM (LPDDR5)
256 GB PCIe SSD
User-accessible MicroSDXC card slot

GRAPHICS

Intel® Gen12 UHD Graphics

DISPLAY

Active viewing area: 7” (178 mm)
Resolution: WXGA (1280 x 800)
High-visibility backlit LCD for best-in-class sunlight view-ability
Portrait or landscape orientation with automatic screen rotation

TOUCH SCREEN

Projected capacitive multi-touch interface for use with gloves, small tip stylus, and in wet conditions
Optically bonded for increased visibility and strength
Chemically-strengthened Dragontrail™ High lon- Exchange (HIE™) cover glass for excellent impact and scratch resistance

KEYBOARD

Adjustable LED backlit keys
Four-way directional navpad
Windows/home key
Power key
Enter key
Three user-programmable function keys

PORTS

USB-A (5Gbps) x 1
USB-C (5Gbps) x 1
12 VDC power input jack
Docking port connections (Power, USB 2.0)
Loud output speaker for noisy environments
Dual digital microphone input for improved clarity

BATTERY

Removable Li-Ion battery, 43.2 Whr
Operates up to 15 hours on one charge
Removable battery, easily changeable in field
Optimized for strong performance in cold temperatures
Excellent lifecycle performance

PHYSICAL

Size: 5.40” w x 8.48” I x 1.36” d (137 x 215 x 35 mm)
Weight: 1.5lbs (680g) without swappable battery
Durable, chemical- and shock-resistant design
Easy-to-grip, impact-absorbing, overmolded bumpers
Lightweight and ergonomic design

WIRELESS CONNECTIVITY

Long-range Bluetooth® Smart Ready wireless technology, v5.3 + EDR, Class 1.5, BLE support
Wi-Fi 6 (802.11 ax), 2.4 GHz and 5 GHz Wi-Fi 6E
4G LTE multi-carrier capable

CAMERA

Rear: 13 MP with LED illumination
Front: 5 MP
Juniper Geotagging™: embed photo with date, time, and GNSS position

GPS/GNSS

2 to 5 meter typical accuracy
Quectel LC79H
Integrated real-time SBAS receiver (WAAS, EGNOS, etc.)
135 GNSS tracking channels

OTHER FEATURES

Ambient light sensor
Compass
Accelerometer
Gyroscope
TPM (Trusted Platform Module) v2.0

CERTIFICATIONS AND STANDARDS

FCC and ISED Certification (USA and Canada)
FCC Class B and ICES-003 Class B (USA and Canada)
CE Marking (EU Radio Equipment and RoHS Directives)
ACMA RCM (Australia)
United States Toxic Substances Control Act (TSCA)
California Prop 65
Canada Prohibition of Certain Toxic Substances
EU REACH, EU POP, SCIP, WEEE

JUNIPER RUGGED™

IP68 waterproof and dustproof
Operating Temperature: -4° F to 122° F (-20° C to 50° C)
Storage temperature: -22° F to 158° F (-30° C to 70° C)
Shockproof: multiple drops from 4’ (1.2–1.5 m) onto concrete
Designed to meet MIL-STD-810H test procedures: Method 501.7 High Temperature; Method 502.7 Low Temperature; Method 503.7 Temperature Shock; Method 507.6 Humidity; Method 514.8 Vibration; Method 516.8 Shock

WARRANTY

2-Year Warranty
Service Plans Available

STANDARD ACCESSORIES

Standard removable battery
AC wall charger with international plug kit
Capacitive small-tip stylus w/tether
Hand strap
Connector port dust cover

AVAILABLE ACCESSORIES

Powered stylus
Detachable keyboard
