Carlson Takeoff Suite

$7,500.00

Carlson Takeoff Suite is a bundle that includes Carlson Construction, Carlson CADNet, Carlson GeoTech & Carlson Trench. It can run standalone with the included license of IntelliCAD or on top of a separately purchased license of full AutoCAD.

See Available Discounts in Cart

Options:

Quantity:
Category:

Description

Carlson Takeoff Suite is a bundle that includes Carlson Construction, Carlson CADNet, Carlson GeoTech & Carlson Trench. It can run standalone with the included license of IntelliCAD or on top of a separately purchased license of full AutoCAD.

Carlson Takeoff Suite is a hybrid program that is most comparable to construction estimating software such as Paydirt, Quest and Agtek. However, it also contains much of the same general functionality of the civil design components of programs such as: DCA/Softdesk/Land Desktop, AutoCAD Map, Civil 3d, Raster Design, Eagle Point, TerraModel, GeoPak and InRoads.

All Carlson Software purchases will be delivered by email with your new serial number and download instructions within two business days.

System Requirements

For Carlson’s CAD-Based Products

Note: Carlson products installed on top of the CAD products of IntelliCAD or AutoCAD, are subject to the same requirements as the CAD engine itself. Please follow the requirements for the CAD platform listed below and allow an additional 750 MB of hard-drive space for the Carlson application.

Carlson 2016-2018 with IntelliCAD 8.x

  • Compatible with 32 or 64 bit Windows Vista, 7, 8, 8.1, and 10
  • For hardware requirements, see Carlson 2013-2015* below

Carlson 2013-2015* with IntelliCAD 7.2

*Starting with 2013 build 130120

Intel® Pentium® 4 or comparable (minimum), Intel i7 or at least Intel i5 or comparable (recommended). Due to the variety of processors on the market, one can use cpubenchmark.net/cpu_list.php to do comparative analysis. While the overall processor score matters, the single thread performance is of the most interest.

  • 32-bit Windows 7-8.1: 1 gigabyte (GB) of RAM minimum for, 4 GB recommended.
  • 64-bit Windows 7-8.1: 2 GB of RAM minimum for, 8+ GB recommended.
  • Windows Vista: 1 GB of RAM minimum, 4 GB recommended.
  • Windows XP: 512 megabytes (MB) of RAM minimum, 2 GB recommended.

Graphics card compatible with OpenGL Version 1.4 or higher:

  • Recommended are desktop graphics level discrete (not integrated cards like Intel HD) graphics cards.
  • Preferably Nvidia Geforce due to their more consistent driver support.
  • Discrete ATI/AMD cards will be adequate, but ATI’s driver support has been spotty and user is frequently deferred to the computer manufacturer for support.
  • Professional Nvidia Quadro cards are not currently recommended due to driver issues.
  • Powerful gaming cards are not required and probably would not provide as much benefit as investment in more memory or better CPU

Carlson 2012 and earlier with IntelliCAD 7.1 and 6.x based products

  • Windows® XP, Windows® Vista, Windows® 7
  • Intel Pentium® or more powerful processor
  • 64-bit machines are supported, but application itself is 32-bit
  • 1 GB RAM (minimum), 4 GB recommended (for complex drawings)
  • 400 MB of free hard disk space (1.2 GB Total, see Note above)

AutoCAD®

Please visit the AutoCAD System Requirements page for current specifications which are subject to change without advance notice.

Please visit the Autodesk summary of the Operating system compatibility for AutoCAD (Autodesk Bulletin TS14078105) for historical references between AutoCAD and its supported operating system(s).

Please see Note above for hard disk space requirements for the Carlson application.

Embedded AutoCAD® OEM Engine

Carlson solutions based on AutoCAD 2018 Embedded

Takeoff R10 / Survey OEM 2018

Please note the CPU compatibility below: older AMD CPUs like Athlon XP+ do not support SSE2 technology and can not run Embedded AutoCAD 2018 products.

  • Microsoft Windows 10 (64-bit only); Microsoft Windows 8.1 with Update KB2919355 (32-bit & 64-bit); Microsoft® Windows® 7 SP1 (32-bit & 64-bit)
  • 4 GB RAM (minimum), 8 GB (recommended)
  • 2 GB free disk space for installation
  • 1360 x 768 (1920 x 1080 recommended) with True Color
  • Windows Internet Explorer® 11 or later
  • Install from download or DVD

Carlson solutions based on AutoCAD 2013 Embedded

Takeoff R6, R7, R8, R9 / Survey OEM 2013, 2014, 2015, 2016, 2017

Please note the CPU compatibility below: older AMD CPUs like Athlon XP+ do not support SSE2 technology and can not run Embedded AutoCAD 2013 products.

  • Windows® 8 and 10 Standard, Enterprise, or Professional edition (8 requires installation of AutoCAD LT 2013 Service Pack 2); Microsoft® Windows® 7 Enterprise, Ultimate, Professional, or Home Premium edition (SP3 or later) with an Intel® Pentium® 4 or AMD Athlon™ dual-core processor, 3.0 GHz or higher with SSE2 technology.
  • 1 GB RAM (minimum), 8 GB (recommended)
  • 1.4 GB free disk space for installation
  • 1,024 x 768 VGA display with true color
  • Internet Explorer 7.0 or later
  • Install from download or DVD

Carlson solutions based on AutoCAD 2010 Embedded

Takeoff R4, R5 / Survey OEM 2010, 2011, 2012

Please note the CPU compatibility below: older AMD CPUs like Athlon XP+ do not support SSE2 technology and can not run Embedded AutoCAD 2010 products.

  • Microsoft Windows 7, or,
  • Windows Vista, SP1 or later (Enterprise, Business, Ultimate, Home Premium) operating system, with,
  • Intel Pentium 4 processor or AMD Athlon dual-core processor, 3.0 GHz or greater with SSE2 technology
  • 1 GB RAM (minimum), 8 GB (recommended)
  • 850 MB free disk space for installation
  • 1024 x 768 VGA display with true color
  • Microsoft Internet Explorer 7.0 web browser or later
  • DVD drive

Or

  • Microsoft Windows XP Professional or Home Edition operating system (SP2 or later), with,
  • Intel Pentium 4 or AMD Athlon dual-core processor, 1.6 GHz or greater with SSE2 technology
  • 512 MB RAM
  • 850 MB free disk space for installation
  • 1024 x 768 VGA display with true color
  • Microsoft Internet Explorer 7.0 web browser or later
  • DVD drive

Carlson solutions based on AutoCAD 2007 Embedded

Takeoff R2, R3 / Survey OEM 2007, 2008, 2009
  • Microsoft Windows 7, or,
  • Windows Vista, or,
  • Windows XP Home or Professional SP1 or better, or,
  • Windows XP for Tablet PC SP2, or,
  • Windows 2000 SP3 or better
  • Pentium III 800 minimum, Intel Pentium IV recommended
  • 512 MB RAM
  • 550 MB free disk space for installation
  • 1024 x 768 with True Color
  • Microsoft Internet Explorer 6.0 SP1 or higher
  • CD-ROM drive
  • Mouse, trackball, or compatible pointing device

Carlson solutions based on AutoCAD 2004 Embedded

Takeoff R1 / Survey OEM 2004, 2005, 2006
  • Microsoft Windows XP (Professional, Home Edition, or Tablet PC Edition), or,
  • Windows 2000, or Windows NT 4.0 (SP6a or later)
  • Pentium III 800 minimum, Intel Pentium IV recommended
  • 256 MB RAM
  • 300 MB free disk space for installation
  • 1024 x 768 VGA with true color (minimum)
  • Microsoft Internet Explorer 6.0
  • Mouse, trackball, or compatible pointing device
  • CD-ROM drive

Videos

Free Support

Carlson Software Works For You

A customer’s relationship with Carlson Software goes beyond simply purchasing our software – with Regional Managers throughout the country, free technical support for life, and training options for any budget – we’ve got you covered!

Direct Technical Support
  • Hours: Monday – Friday, 8:00 AM – 6:00 PM (EST)
  • E-mail: support@carlsonsw.com
  • Problems/Suggestions: Send in a report
  • Telephone: 606-564-5028
  • Fax: 606-564-6422

Improvements

Improvements for Takeoff R11

General

  • Migration Wizard – New command to transfer program settings and files between program versions.
  • Carlson Academy – New command for on-line learning with movies, blogs and data sets.
  • Ultra High Resolution Displays – Improved font and image scaling for dialogs.
  • LandXML – Added method to export 3D polylines as alignments.
  • Open Drawing – New command to select geo-located drawings from a map view.
  • File Selection – Expanded list of files in current folder and added ability to sort by the file name, size or date.
  • Drawing Explorer – Added Carlson surface objects, more right-click commands and setup double-click commands.
  • MText Labels – Routines with option to hide drawing under the text use the mtext background mask instead of separate wipeout entity. Applies to commands such as Triangulate & Contour for contour labels and Leader With Text.
  • Zoom Most – New command to zoom to show the bulk of the entities in the drawing and avoid outliers.
  • 3D Viewers – Major performance improvements for handling large models. Added method to use different textures for surfaces based on slope. Added method to color the surface by the normals of the 3D faces. Added display of x,y,z coordinates for position of the cursor on the surface. Added control for thickness of linework. Added keyboard controls for panning and zooming the scene. Added clip planes from top and bottom, plus way to enter elevations or screen pick clip plane position. Added x-ray view mode to make surface transparent in window around the cursor. Added method to select more entities from the drawing to add to the current scene. Pick mode displays distance from previous pick point. Added option to label the bounding box with x,y,z. Added methods to texture surface by slope range and to substitute a texture per color. Added setting for pixel size to draw point entities. Added keyboard hot-keys to rotate left/right and up/down. Added settings for default surface colors.
  • Centroid Point – Added support for calculating the centroid for a solid model.
  • Draw 3D Polyline – Elevation prompt has new method to add or subtract an amount like for a curb.
  • Hatch Wizard – Added auto-connect mode to make closed areas from selected linework.
  • Boundary Polyline – Added method to create closed polylines for all the areas from the input linework.
  • Edit Table Properties – Added method to automatically create multi-line rows for long labels.
  • Text on Line/Polyline – Added method to select label polyline by picking a crossing line and added options to hide the drawing under the labels, to center the text on the line and to repeat the placement.
  • White Solid Behind Text – Added setting for layer name.
  • Output Layouts to PDF – Added option to optimize geometry.
  • Drawing Setup – Added optional field for project location to include in reports and use for geolocating.
  • Report Formatter – Improved Import/Export to process selected reports and avoid name conflicts.

Takeoff Commands

  • Takeoff Surfaces – Added options to densify breaklines.
  • Assign Contour Elevations by Label – Allow processing multiple layers for the contour lines.
  • Edit Assign Polyline Elevations – Added a dynamic profile view in the dialog. Added by crossings option to add vertex on reference crossing polylines. Added option to label non-control points and setting for label alignment.
  • Trench Quantities By Profiles – New command to calculate trench quantities using trench and surface profiles.
  • Define Layer Surface/Material/Subgrade – Added method to create solids of subgrades.
  • Display Surface – Added option to draw triangulation as a surface object.
  • Edit Assign Polyline Elevations – Added function to set elevation from a surface model, and added reduce function option to retain all control points. Polyline edits automatically update TIN surfaces that include the polyline.
  • Make Combined Removal Surface – New command to make a TIN surface from all the removal surfaces.
  • GeoTech Edit Drillhole – Uses strata attributes from Define Attributes and drillhole attributes from Define Lookup Database.
  • Raster Decompress – Added support for TIFF image in LZW compression.
  • Export Solid Model IFC File – New command to create an IFC model from a Carlson solid model.
  • Rubber Sheet – Added mesh transformation method. Added initial transform when destination control points are outside original image. Added report of control points. Added import/export functions for control points.

Point Commands

  • Draw Points – Added option to limit the length of the drawn description and notes.
  • Edit Points – Added a toolbar to the dialog for quicker access to common functions.
  • Point Group Manager – Added functions to sort the groups by name or number of points.
  • Cut Sheet – Added option to set colors for cut and fill labels.
